Gr9 Gr10 Gr12 Round Titanium Welded Pipe 6-12m ASTM B338

Shandong Xiangtong Huiyuan Metal Materials Co., Ltd.
Contact Now

Gr9 Gr10 Gr12 Round Titanium Welded Pipe 6-12m ASTM B338

  • 1
  • 2
  • 3

Brand Name : NO

Model Number : Gr9,Gr10

Certification : ISO

Place of Origin : China

MOQ : 1 TONS

Price : USD 20000-35000 per Ton

Payment Terms : L/C, D/A, D/P, T/T, MoneyGram

Supply Ability : 900 Tons per Month

Delivery Time : 15-21 DAYS

Packaging Details : Standard package, according to customer requirement.

Color : Customer's Request

Shape : Round,Square

Length : ≤3000mm

Thickness : Based on your requirements.

MOQ : 3Tons

Grade : GR9 GR12 GR10

Payment : 30%TT+70%TT

Standard : ASTM B338 B337 B861 B862

Contact Now

Gr9,Gr10,Gr12 Titanium Steel Pipe High Quality Length 6-12m In China

Wall Thickness:0.3-120mm



Inside Diameter:2-219mm



Processing Service:Cutting



Product Name:Titanium Tubing





Application:Industrial



Grade:Gr1,Gr2,Gr5,Gr7,Gr9,Gr10,Gr12



Processing Service:Bending, Welding, Decoiling, Cutting, Punching



Titanium pipes implement two national standards according to the different requirements and performance: GB/T3624-2010 GB/T3625-2007 ASTM B337 338.

Supply grades: TA0, TA1, TA2, TA9, TA10, BT1-00, BT1-0, Gr1, Gr2.Gr9.Gr10.Gr12.



The titanium tube is light in weight, high in strength and superior in mechanical properties. It is widely used in heat exchange equipment, such as tube and tube heat exchangers, coil heat exchangers, serpentine tube heat exchangers, condensers, evaporators and transportation pipelines. Many nuclear power industries use titanium tubes as standard tubes for their units.



Standard:

1.GB 228 Metal Tensile Test Method

2. GB 224 Metal Pipe Hydraulic Test Method

3. GB 226 Metal Tube Flattening Test Method

4. GB/T3620.1 Titanium and titanium alloy grades and chemical composition

5. GB/T3620.2 Chemical composition and composition tolerance of titanium and titanium alloy processed products



Product   Titanium and Titanium alloy seamless tube & pipe
Size   Cold-rolled:
  OD: 8.0mm-114.0mm (0.32"-4.49"), WT: 0.5mm-7.5mm (0.02"-0.30"), Length: 4000mm       (157.5") max (OD.: 8.0mm-15.0mm, 0.32"-0.59"),
  12000mm (472.4") max (OD. over 15mm, 0.59")
  Extruded:
  OD: 25mm-210mm (0.98"-8.27"), WT: 4mm-30mm (0.157"-1.18"), Length: 1000mm-     10000mm (39.4"-393.7")
Material   Gr.1, Gr.2, Gr.3, Gr.7, Gr.9, Gr.12, etc.
Standard   ASTM B 338, ASTM B 337, ASTM B 861
Shape   Round


Specification:

OD(mm) 8.0-10.0 10.0-15.0 15.0-20.0 20.0-25.0 25.0-30.0 30.0-35.0
WT(mm) 0.15-2.0 0.2-2.0 0.4-2.7 0.45-3.2 0.45-3.3 0.45-3.4
OD(mm) 35.0-40.0 41.0-45.0 46.0-50.0 51.0-55.0 56.0-60.0 61.0-65.0
WT(mm) 0.5-3.5 0.6-3.8 0.6-3.8 0.6-4.4 0.8-4.6 0.9-4.7
OD(mm) 66.0-70.0> 71.0-75.0> 76.0-95.0 96.0-114.0 - -
WT(mm) 1.0-4.9 1.2-6.0> 1.2-7.1 1.3-7.5 - -

Gr9 Gr10 Gr12 Round Titanium Welded Pipe 6-12m ASTM B338

Gr9 Gr10 Gr12 Round Titanium Welded Pipe 6-12m ASTM B338

Gr9 Gr10 Gr12 Round Titanium Welded Pipe 6-12m ASTM B338

Gr9 Gr10 Gr12 Round Titanium Welded Pipe 6-12m ASTM B338





FAQ

Q: Do you accept sample order?

A: Yes sure, please contact us for details.
Q: How about your after-sales service?
A: As a professional steel exporter, we offer promote technology support for all problems and questions.
    Besides, we accept goods return or replace for quality problem.

Q: How about the delivery terms?

A: 1. Payment: T/T, 30% deposit in advance and balance before delivery.
     2. Min. Order Quantity:3TON or as required.
     3. Transportation: By express (DHL,TNT,),air,sea,and train
